This new series forklift trucks that made with the latest technical design provide you excellent operating performance. HELI forklift trucks high standard performance, comfortable driving experience and the simple and safe operation will make your work handier.
| Model | | CPCD280-V. | CPCD300-V. | CPCD320-V. |
| Power type | | Diesel |
| Load capacity | kg | 28000 | 30000 | 32000 |
| Load center | mm | 1200 |
| Max. lifting height | mm | 4000 |
| Overall length(without forks) | mm | 6800 |
| Overall width | mm | 3450 |
| Overall height(cab) | mm | 3930 |
| Min. turning radius | mm | 6395 |
| Max. travel speed(without load) | Km/h | 26 | 25 |
| Service weight | kg | 40000 | 41500 | 43000
|
VOLVO Diesel engine, comply to EPA standards on None-road application, with genuine attached parts to guarantee the normal use and maintenance.
ZF Transmission system. This transmission system integrated various control software in one controller, easy to handle. It can also be diagnosed easily with the diagnostic machine interface.
Kessler Front Axle. This Axle has high load capacity and brake torque to be safe and reliable enough. Wet type brake is water-resistant and dust-resistant and maintenance free.
Parker Main Hydraulic system. Using prior-steering strategy Pre-open valve on Multicontrol Valve to separate the operation level and control valve to realize remote control. It can be operated with comfort and safety and release the tension of the driver.
The mast is very strong and durable, and with integral side-shifting fork positioner. It’s unnecessary to fit additional side shift.
Environmental Friendly
- The emission meets EC and EPA new regulation.
- High efficiency hydraulic system to lower the fuel consumption.
- Using environmental friendly material.
- Damping device on the mast to reduce impact and vibration.
- Sound insulating and absorbing device are used to reduce the noise.
Ergonomics design
- Using power braking system to reduce footplate strength.
- Control lever right located to effectively reduce drivers arm tiredness.
- Dual combined switch lever as a car to enable easy operating.
- Wide mast with good visibility.
- Wide space for boarding and driving , increasing leg space.
- Engine automatic monitor control, when the engine oil pressure is too low or water temperature is too high, the engine will be automatically shut off.
Safety performance
- Enclose cabin is made of assembling steel plate, high strength overhead is designed to ensure the safety.
- Parking brake with safety protection device, when parking brake is working, the forklift will not move even the direction lever is turned.
- Safety device in mast hydraulic system prevents material falling down in of hose broken.
- High pressure hose is designed far away from the driver.
- Safety wire harness, using waterproof plug.
